Product features

• Hot-swappable OSFP Type2 dimensions

• With a closed top radiator

• Supports 2x425Gb/s aggregated bit rate

• Power consumption <16W

• Complies with RoHS regulations

• The laser eye grade is 1M

• The shell temperature range is from 0°C to +70°C (C temperature).

• Single 3.3V power supply

• Complies with IEEE 802.3db

• 8x100G PAM4 re-timing 106.25Gb/s

• The PAM4 electrical interface complies with IEEE 802.3ck

• Dual MPO-12 APC sockets

• I2C management interface

Application

• Unlimited Broadband Center

• 800G SR8/VR8 Application with FEC

• 2x400G SR4/VR4 Application with FEC

• 8 x 100GbE branch application

Product features

• Hot-swappable Type 2 OSFP dimensions

• Supports an aggregated bit rate of 850Gb/s

• Power consumption <17W

• Complies with RoHS-6 requirements

• The shell temperature range is 20°C to +60°C (limit temperature) or 0°C to +70°C (c temperature).

• Single 3.3V power supply

• Complies with IEEE 802.3bs requirements

• 8x100G PAM4 re-timing 106.25Gb/s PAM4 electrical, interface complies with IEEE 802.3ck requirements

• Dual MPO-12 and APC sockets

• I2C management interface

Application

• 8 x 100GbE Application

• 2 x 400GbE Application

• 4 x 200Gbe Application

• NDR Unlimited broadband
